今天我們通過內核中的源碼共同分析一下Linux設備驅動中申請?jiān)O(shè)備號的過程，首先在Linux內核為我們提供了兩種申請?jiān)O(shè)備號的方式，一是指定設備號注冊，二是動態分配設備號；分別用到一下兩個函數：

 register_chrdev_region();

 alloc_chrdev_region();

設備號的數據類型是dev_t類型，是一個無符號長整型，在32位操作系統中，它的大小是4個字節，32位，高12位用來存放主設備號，低20位用來存放次設備號。

通過主設備號和次設備號合成設備號的宏如下：

MKDEV(major,minor);

從設備號中提取主設備號和次設備號的宏如下：

MAJOR（dev）；

MINOR（dev）；

接下來我們就來分析設備號注冊過程：

一、自動分配設備號：

1.  調用內核提供的自動分配設備號函數，分配設備號

int alloc_chrdev_region(dev_t *dev, unsigned baseminor, unsigned count,const char *name)

2. alloc_chrdev_region函數中繼續調用如下函數，進行進一步申請

struct char_device_struct *cd =  __register_chrdev_region(0, baseminor, count, name);

/*在該函數中進行判斷，如果major==0,執行if內的語句*/

if (major == 0) {                     //自動分配時major == 0

/*

*chrdevs是一個結構體指針數組，見附錄1-1

*作用是從struct char_device_struct類型的結構體指針數組中找到一個空的結構體指針

*/

for (i = ARRAY_SIZE(chrdevs)-1; i > 0; i--) {  // for(i=254;i>0;i--)

if (chrdevs[i] == NULL)

break;

}

if (i == 0) {      //i == 0 ,說明，存放設備號的結構體指針數組已經用完

ret = -EBUSY;

goto out;

}

major = i;         //否則，主設備號 = i

ret = major;

cd->major = major;                       // 將主設備號賦值給cd->major

cd->baseminor = baseminor;       // 將起始次設備號賦值cd->baseminor

cd->minorct = minorct;    // 將傳入的第三個參數賦值給程cd->minorct,

                                                     // 表示申請?jiān)O(shè)備號的個數

strlcpy(cd->name, name, sizeof(cd->name));  //設備名拷貝

/*

*struct char_device_struct *cd, **cp;

*cp存放的是結構體指針的地址，基于當前的條件，*cp == NULL ，所以for循環條件不成立

*/

--------------------------------------不執行-------------------------------------

for (cp = &chrdevs[i]; *cp; cp = &(*cp)->next)

if ((*cp)->major > major ||((*cp)->major == major &&(((*cp)->baseminor >= baseminor) ||((*cp)->baseminor + (*cp)->minorct > baseminor))))

break;

---------------------------------------------------------------------------------------

/*     **cp == NULL ，所以條件不成立*/

---------------------------------------不執行-----------------------------------------

if (*cp && (*cp)->major == major) {

int old_min = (*cp)->baseminor;

int old_max = (*cp)->baseminor + (*cp)->minorct - 1;

int new_min = baseminor;

int new_max = baseminor + minorct - 1;

/* New driver overlaps from the left.  */

if (new_max >= old_min && new_max <= old_max) {

ret = -EBUSY;

goto out;

}

/* New driver overlaps from the right.  */

if (new_min <= old_max && new_min >= old_min) {

ret = -EBUSY;

goto out;

}

}

---------------------------------------------------------------------------------------

cd->next = *cp;                  //cd ->next = NULL

*cp = cd;  //*cp[chrdevs[i]] , cd 結構體在上面賦值的

mutex_unlock(&chrdevs_lock);

return cd;

回到alloc_chrdev_region函數的*dev = MKDEV(cd->major, cd->baseminor);

實際上就申請了一個主設備號，次設備號

二、用戶指定設備號注冊（eg：major = 250；count=3）

1. int register_chrdev_region(dev_t from, unsigned count, const char *name);

2. 在該函數中進行如下操作：

dev_t to = from + count;      // dev_t to =  MKDEV(dev_major,dev_minor) +3;

dev_t n, next;

/*如果申請的設備編號范圍跨越了主設備號，

*它會把分配范圍內的編號按主設備號分割

 *成較小的子范圍，并在每個子范圍上調用

 *__register_chrdev_region() 。如果其中

*有一次分配失敗的話，那會把之前成功分配的都全部退回*/

// for(n = MKDEV(dev_major,dev_minor); n<to;n=next)循環一次（next = to）

for (n = from; n < to; n = next) {

next = MKDEV(MAJOR(n)+1, 0);         // next = MKDEV(250+1,0);

if (next > to)                       // if(MKDEV(251,0)>MKDEV(250,0)+3) [成立]

next = to;                          // next = MKDEV(250,0)+3

cd = __register_chrdev_region(MAJOR(n), MINOR(n),next - n, name);

//__register_chrdev_region(250, 0,3, "xxx_demo");

      {

 cd->major = major;           //cd->major = 250;

cd->baseminor = baseminor;   //cd->baseminor = 0;

cd->minorct = minorct;           //cd->minorct  = 3;

strlcpy(cd->name, name, sizeof(cd->name));

i = major_to_index(major);   //i = 250;

/*for (cp = &chrdevs[250]; *cp; cp = &(*cp)->next)*/

for (cp = &chrdevs[i]; *cp; cp = &(*cp)->next)

if((*cp)->major > major || ((*cp)->major == major &&(((*cp)->baseminor >= baseminor) ||((*cp)->baseminor + (*cp)->minorct > baseminor))))    //正常情況下不會成立，即次設備號范圍不會重復

break;



/*判斷次設備號范圍是否重復，如果重復就錯誤返回*/

if (*cp && (*cp)->major == major) {

int old_min = (*cp)->baseminor;

int old_max = (*cp)->baseminor + (*cp)->minorct - 1;

int new_min = baseminor;

int new_max = baseminor + minorct - 1;

/* New driver overlaps from the left.  */

if (new_max >= old_min && new_max <= old_max) {

ret = -EBUSY;

goto out;

}

/* New driver overlaps from the right.  */

if (new_min <= old_max && new_min >= old_min) {

ret = -EBUSY;

goto out;

}

}

/*將設備號的結構體插入到散列表中*/

 cd->next = *cp

 *cp = cd;

 }

附錄1-1：



#define CHRDEV_MAJOR_HASH_SIZE 255

static struct char_device_struct {

struct char_device_struct *next;

unsigned int major;

unsigned int baseminor;

int minorct;

char name[64];

struct cdev *cdev; /* will die */

} *chrdevs[CHRDEV_MAJOR_HASH_SIZE];

附錄1-2
